Ultrasonic Lace Sewing Machine For Cutting Lace

Ultrasonic Lace Sewing Machine For Cutting Lace

The basic configuration of ultrasonic non-woven welding machine includes new intelligent ultrasonic generator, bottom mold with synchronous rotation function, two-way motor speed control system, manual (or optional pneumatic) pattern lifting system, multi-functional pattern bracket and level Fine-tuning mechanism and double-tube rack heavy platen.
Send Inquiry

Ultrasonic non-woven fabric sewing machine features:

1. Ultrasonic power is up to 2000W, and it has large, medium and small power adjustment functions to meet the welding and cutting requirements of different materials and thicknesses;

2. Built-in computer chip, multi-channel ultrasonic protection system to ensure safe and stable operation of the host;

3. The bottom mold rotation function makes the chassis wear evenly, prolong the service life and improve the processing quality;

4. The frequency automatic tracking system and the application of ultrasonic soft start technology, so that the performance of this machine reaches the international level.

Advantages and applications of ultrasonic non-woven fabric sewing machine:

This product is suitable for knitting products, bed covers, Christmas ornaments, ribbons, ready-to-wear, lace and other products. It is ergonomically designed, comfortable to operate, and can be used for curves, straight-line melting and other functions, eliminating the trouble of assembling needles, wires and spools of traditional sewing machines. The equipment can operate continuously at high speed, with high production efficiency, which can improve quality and create profits.


Good Description:Ultrasonic lace sewing machine
Model:SW20-2000
Voltage Supply:220V±5V 50Hz (60Hz), 110V available.
Install Power:2000W
Ultrasonic Frequency:20KHz
Working Speed:0-10m/min, adjustable.
Pattern Width:100mm
Pattern Roller Sizes:50MMxØ51MM; 100MMxØ51MM
Materials Suitable:polyester, nylon, chemical and non-woven fabrics.
Usages:Making laces, sewing (welding), cutting and non-woven products.
Packing Size:L (130cm)x W(60cm)x H(130cm)
Gross Weight:150KGS
