Ultrasonic Herb Extraction Machine

Ultrasonic extraction device is the use of ultrasonic cavitation, mechanical effect and thermal effect in order to improve the contents of a cell penetrating power and transmission capacity, increase material molecular motion frequency and speed, increase the leaching rate of herbal medicine composition....

Send Inquiry

ultrasonic herb extraction machine

Ultrasonic extraction device is the use of ultrasonic cavitation, mechanical effect and thermal effect in order to improve the contents of a cell penetrating power and transmission capacity, increase material molecular motion frequency and speed, increase the leaching rate of herbal medicine composition.

Ultrasonic extraction machine can help plants to the wall or tissue deformation, make medicine effective components extraction, more fully in 24-40 minutes to get the best extraction yield (withdrawal rate significantly higher than the traditional process of up to 50-500%), extraction time is greatly shortened 60% of the traditional method, medicine raw materials processing.


Description

Power

1000W

1500W

2000W

3000W

Frequency

20Khz

Amplitude/power adjustment range

50-100%

20-100%

Temperature

<300℃

Volume of reactor

5-100L

Standard Spec

Ultrasonic device + Digital Generator

Optional  configuration

Stainless steel reactor, Remote communication interface, flow meter, pump, mechanical mixer


Application of Ultrasonic Sonochemistry:

3000w 20khz ultrasonic mixing machine for sonochemistry

• Cell disruption • Pharmacy sample prep • Homogenization • Emulsification • Nanoparticle dispersion • Atomization • Graphene dispersion • Biodiesel making; • Liquidation, • Crystallization, • Extraction, • Wastewater treatment, • Accelerated reaction, • kill microbes(cell disruption).
