Ultrasonic Impendance Analyzer Testing Machine

It is characteristic of analyzer measurement and evaluation of piezoelectric ceramics, piezoelectric transducer, ultrasonic cleaning machine, ultrasonic welding machine, ultrasonic grinder, ultrasonic machining equipment and other devices, the device parameters and performance.


It is characteristic of analyzer measurement and evaluation of piezoelectric ceramics, piezoelectric transducer, ultrasonic cleaning machine, ultrasonic welding machine, ultrasonic grinder, ultrasonic machining equipment and other devices, the device parameters and performance.

Transducer impedance tester is characterized by easy to use, the combination of indicators and graphics, accurate parameters, low prices, strong guidance for production, etc.


ZY C260A

ZY C360A

Frequency range

1KHz-500KHz

1KHz-1MHz

Measuring speed

10s/pcs

4s/pcs

Measurement index

Fs、Fp、F2、F1、R1、Qm、Gmax、CT、L1、C1、C0、Keff、Kp

measurement accuracy

<1%

Frequency accuracy

±10ppm

Range

0.1Ω-1MΩ

stepped-frequency

0.1Hz-other

Application

Power ultrasonic and piezoelectric ceramic batch inspection
