Ultrasonic vibrator, also known as ultrasonic vibrator, the industry after the transducer and the horn connected to the whole is called the vibrator. Ultrasonic vibrator Piezoelectric ceramic piezoelectric effect to achieve the conversion of electrical energy and mechanical energy (acoustic vibration), and through the acoustic impedance matching front and rear radiation cover block amplification device.

Ultrasonic transducer consists of ultrasonic transducer and ultrasonic horn. Ultrasonic transducer is a device that can convert high-frequency electric energy into mechanical energy. Ultrasonic horn is a passive device that does not generate vibration itself. It only transfers the vibration input by the ultrasonic transducer and then sends it out to complete Impedance transformation.


The upside-down type BRANSON TYPE (Larger amplitude and bigger output power, high-sound intensity and high-power density application)

Item No.

Connect screw (Size)

Ceramic diameter (mm)

Quantity of Ceramic(pc)

Resonance frequency (khz)

Resistance (Ω)

Capacitance

Input
power (W)

Max.
Amplitude (um)

Yellow

Grey

Black

7015-4ZD

M20 X 1.5

70

4

15

15

12500-14000

/

17000-19000

2600

11

6015-4ZD

M18 X 1.5

60

4

15

15

9000-10000

10000-11000

/

2200

11

6015-6ZD

1/2-20UNF

60

6

15

15

19000-20500

/

23000-25000

2600

11

5015-6ZD

1/2-20UNF

50

6

15

15

17000-19000

/

23000-25000

2000

11

5020- 4ZDS

1/2-20UNF

50

4

20

15

11000-12000

12000-13500

/

1300

8

5020-4ZD

1/2-20UNF

50

4

20

15

11000-12000

12000-13500

14500-16000

1500

8

5020-6ZD

1/2-20UNF

50

6

20

15

19000-21000

/

22500-25000

2000

10

4020-6ZD

1/2-20UNF

40

6

20

15

13500-15000

/

/

1500

10

4020-4ZD

1/2-20UNF

40

4

20

15

8500-9300/ 9500-10500

10000-11000

10500-11500

900

8

3020-6ZD

3/8-24UNF

30

6

20

15

8000-9000

/

/

600

9

3030-4ZD

M8 or M8 X 1

30

4

30

20

/

6200-6900

/

800

5

3535-2ZD

M8 X 1

35

2

35

25

/

/

4500-5000

600

9

3535-4ZD

M8 X 1

35

4

35

20

6600-7400

/

9000-10000

1000

4

3035-4ZD

1/2-20UNF

30

4

35

20

5500-6200

/

9200-10200

800

4

2535-4ZD

M8

25

4

35

25

3900-4300

/

/

500

4

3040-2ZD

M8

30

2

40

30

/

3400-3800

/

500

2

2540-4ZD

M8

25

4

40

30

4500-5300

/

/

500

3

2040-2ZD

M8

20

2

40

40

1100-1300

1150-1350

/

300

2
